GF1800

Front-Mount Tractor

  • Warranty 2 years

Features

Powerful compact lightweight Kubota diesel engine

The 16.6-horsepower diesel engine in each of these front tractors provides high torque rise to handle tough mowing jobs, even in thick grass. Fuel economy is superb with Kubota’s Three Vortex Combustion System (TVCS). You get cleaner exhaust and quiet operation. Rubber engine mounts minimize vibration, and cooling air is discharged to the rear, away from the operator.

Kubota HST

The Hydrostatic transmission with cruise control makes mowing smooth and simple with an easy one-foot-pedal operation.

Hydraulic wet-type multiple-cisc PTO clutch

The hydraulic wet-type multiple-disc PTO clutch is the first in this class. Very durable, it engages smoothly with reduced shock and needs less maintenance. No belts or pulleys are needed.

Easy maintenance

With these front-mount tractors, it’s easy to mount and remove attachments to match your specific needs. The tractor’s battery is within reach for quick servicing. The radiator dust screen is easy to remove for fast cleaning. Changing air and oil filters is fast and simple, since these service areas are easily accessible.

Optional attachments

The GF has a variety of different attachments making this front-mount lawn tractor a great choice for those looking utilize their investment year round.

Specs

Model
Model name
GF1800
Engine
Type
Liquid-cooled Diesel Engine
Rated engine speed
3200 rpm / 3200 rpm
Displacement
43.9 cu. in. / 719 cc
Manufacturer
D722
Engine gross power
16.6 HP / 12.4 kW
Mounting method
Damping Rubber Mount
Number of
Cylinders
3
Fuel system
Fuel type
Diesel
Fluid capacities
Fuel tank capacity
5.3 gal / 20 l
Tires
Front
20 × 10.0 - 8
Rear
16 × 6.5 - 8
Traction
Front based On-Demand 4WD
Dimensions and weight
Overall height
79.9 in / 2030 mm
Overall length
79.4 in / 2018 mm
Overall width
38.2 in / 970 mm
Wheelbase
33.5 in / 850 mm
Counter weight
Standard
Shipping weight (without mower)
1280 lb / 580 kg
Turning radius (left turn)
2WD
13.9 in / 355 mm
4WD
17.3 in / 440 mm
Other
Deck type
Semi-flat
Hour meter
STD on Front Panel
Water temperature indicator
Meter on Front Panel
Tread
Front
28.5 in / 724 mm
Rear
31.3 in / 795 mm
Drive train/transmission
Type
Hydrostatic
Traveling speed
Speed control
System
1 Front Pedal + Cruise Control
Forward
8.4 mph / 13.5 km/h
Reverse
4.1 mph / 6.5 km/h
Chassis, axle and brakes
Brakes
System
Dry internal expanding shoe
Steering
Control type
Rear Wheel
Type
Manual
Tilt steering wheel
Standard
Power take off (PTO)
Clutch
Hydraulic
PTO brake
Wet Disc
Operating area
Seat adjustment
One touch side
Fuel tank indicator
on Front Panel
