RTV520

Utility Vehicles

Starting at $13,091
  • Warranty 2 years

Features

Everyday performance

The powerful 2-cylinder liquid-cooled Kubota engine delivers up to 17 HP for dependable everyday performance. This gives the RTV520 plenty of muscle to tow, haul and get more things done. Plus, all this power makes it fun to drive too.

Elevated comfort

Plenty of space, a plush suspension system and a quiet, low-vibration engine delivers a comfortable ride to your chosen destination—even on unruly terrain.

Travel any terrain

The RTV520’s 54.7” wide stance allows it to work in tighter pathways. Uphill and downhill traversal along with hauling cargo or pulling a trailer is also safer thanks to the Hydrostatic Drive system.

Powerful Kubota liquid-cooled gas EFI engine

The durable engine is liquid-cooled to improve efficiency. The Electronic Fuel Injection gas (EFI) makes starting the engine in cold weather easier and provides instant power with greater throttle control.

Variable Hydrostatic Transmission (VHT)

Delivers great performance on any terrain with smooth and powerful acceleration. Low-speed driving is sublime thanks to smooth throttle control, great traction and increased maneuverability.

Easy to drive

The RTV520 is designed to be easy to operate for any driver, regardless of experience. This is made possible with the VHT, where one-pedal operation, smooth acceleration, and engine-braking increase driver confidence and security.

Heavy-duty cargo bed

The RTV520 comes with an easy-to-access large bed (40.6” x 33.6”) and 440 lbs cargo capacity—offering you plenty of room to work.

Mighty towing power

Employ up to 1168 lbs towing capacity thanks to the RTV520’s reliable engine performance and versatile trailer hitch.

Rugged dependability

Crafted with durable components and precision engineered to battle the elements—the RTV520 is built to outlast your daily challenges.

Reduced vibration

Updates to the engine and overall chassis provides reduced vibration and lower noise to help operators stave off fatigue.

Cab option

Comes with sliding windows, flip out front windshield and a heater to provide shelter and comfort all year round.

Specs

Model
Model name
RTV520
Body colour
Orange, Camouflage (Realtree®*2 Hardwoods®)
Engine
Type
2-cylinder, Gas, OHC, Water-cooled, EFI
Displacement
31.4 cu. in. / 514 cc
Engine gross power
17.4 HP / 13 kW
Drive train/transmission
Max. traveling speed
24.9 mph / 40 km/h
Type
VHT PLUS Variable Hydro Transmission
Wheels
4
Drive system
4WD, w/2WD selection
Gear selection
Hi-Lo range forward, neutral, reverse
Chassis, axle and brakes
Type of rear suspension
Rigid axle, 5-link type
Steering type
Rack & Pinion
Differential lock
Standard; hand operated with mechanical holder
Type of front suspension
Independent, Mac-Pherson strut-type
Brakes
Type
Dry Disk Brakes
Parking brake
Rear Wheel, Hand Brake
Cargo box
Depth
11.3 in / 286 mm
Length
33.6 in / 854 mm
Width
40.6 in / 1033 mm
Volume
8.9 cu. ft. / 0.25 m3
Height
34.4 in / 874 mm
Maximum payload capacity
440 lb / 200 kg
Dimensions and weight
Overall height
74 in / 1880 mm
Wheelbase
70.9 in / 1800 mm
Weight
1378 lb / 625 kg
Turning radius
22.6 in / 6.9 mm
Length
105.1 in / 2670 mm
Width
54.7 in / 1390 mm
Maximum towing capacity
1168 lb / 530 kg
Maximum payload capacity
937 lb / 425 kg
Tread centers
Front
40.2 in / 1020 mm
Rear
41 in / 1040 mm
Ground clearance
Front
8.9 in / 225 mm
Rear
6.7 in / 170 mm
Fluid capacities
Fuel tank capacity
5.3 gal / 20 l
Tires
ATV
Front
24 × 9-12 ATV, 6PLY
Rear
24 × 11-12 ATV, 6PLY
HDWS
Front
24 × 9-12 HDWS, 6PLY
Rear
24 × 11-12 HDWS, 6PLY
Other
Alloy wheel
Opt.
Speedometer
Opt.
Front guard
Opt.
Headrest
Opt.
